Throttle cable

For models with twin pull 'Lego' switchgear

18117562-z 18117562 GU18117562 18 11 75 62
 1811 7562 1811.7562 18.11.75.62

Dimensions:
1160mm outer length, 97mm free length, 5.7mm barrel nipple, 2.9mm barrel nipple

Throttle cable for high bar models, runs from twistgrip to carb

We advise you to measure your existing cable before ordering in case you have a non standard set up.

 19117595 GU19117595 19 11 75 95
 1911 7595 1911.7595 19.11.75.95

Dimensions:
1101mm outer length, 105mm free length, 5.7mm barrel nipple, 2.7mm barrel nipple

Throttle cable for models with standard high top PHF pumper carbs

We advise you to measure your existing cable before ordering in case you have a non standard set up.

28117550-z 28117550 GU28117550 28 11 75 50
 2811 7550 2811.7550 28.11.75.50

Dimensions:
955mm outer length, 92mm free length, 5.7mm barrel nipple, 5.7mm barrel nipple

Throttle cable

We advise you to measure your existing cable before ordering in case you have a non standard set up. Two cables required per bike

29117520-z 29117520 GU29117520 29 11 75 20
 2911 7520 2911.7520 29.11.75.20

Dimensions:
1255mm outer length, 122mm free length, 5.7mm barrel nipple, 2.7mm barrel nipple

Throttle cable

We advise you to measure your existing cable before ordering in case you have a non standard set up.

 30117530 GU30117530 30 11 75 30
 3011 7530 3011.7530 30.11.75.30

Dimensions:
870mm outer length, 185mm free length, 5.7mm barrel nipple, 5.7mm barrel nipple

Throttle cable

Only one cable is required. We advise you to measure your existing cable before ordering in case you have a non standard set up

 01117560 GU01117560 01 11 75 60
 0111 7560 0111.7560 01.11.75.60

Dimensions:
Inner cable 1095 mm Outer cable 870 mm

Throttle cable with 90° adapter and adjuster

Only one cable required. If your bike is has plastic switchgear and a single cable it may have been subject to a factory recall which uses our cable CAA03831, see CaliEVThrottleCableRecall.pdf for details.

We advise you to measure your existing cable before ordering in case you have a non standard set up.

03117500-z 03117500 GU03117500 03 11 75 00
 0311 7500 0311.7500 03.11.75.00

Dimensions:
1135mm outer length, 81mm free length, 5.7mm barrel nipple, 5.7mm barrel nipple

Throttle cable

Only one cable is required. We advise you to measure your existing cable before ordering in case you have a non standard set up.

 29117560 GU29117560 29 11 75 60
 2911 7560 2911.7560 29.11.75.60

Dimensions:
1085mm outer length, 132mm free length, 5.6mm barrel nipple, 5.6mm barrel nipple

Throttle cable injection models

We advise you to measure your existing cable before ordering in case you have a non standard set up.

 30117570 GU30117570 30 11 75 70
 3011 7570 3011.7570 30.11.75.70

Dimensions:
Inner: 1118 mm Outer 1000mm

Throttle cable

Only one cable required. If your bike is has plastic switchgear and a single cable it may have been subject to a factory recall which uses our cable CAA03831, see CaliEVThrottleCableRecall.pdf for details.

We advise you to measure your existing cable before ordering in case you have a non standard set up.

 03117530 GU03117530 03 11 75 30
 0311 7530 0311.7530 03.11.75.30

Dimensions:
Inner cable: 1270 mm, outer cable: 1130 mm
