Brembo brake caliper rebuild kit for one P2 F08 (P8) caliper, contains 2 pairs of seals, O ring and 2 M10 bolts

This seal kit is for F08 calipers fitted to front of all these models. Also used on some Triumph Bonnevilles, MZs, Ducati 600 Pantah, 500 Pantah, 500 Sport Desmo, 500 GTV, 650 SL, 750 F1, 750 F1B, 750 Paso, 750 Sport, 900 MHR, 900 SS, 900 S2, 906 Paso, 100 R1, 100 S2 Desmo, Laverda Jota 1000 and Laverda 1200 Anniversary. Brembo ref. 120274110

See BRA10310 for less expensive replica kit

 14659000 GU14659000 14 65 90 00
 1465 9000 1465.9000 14.65.90.00

Also fits Benelli 354, Benelli Sei, Ducati 250/350/450 Desmo (-1976), Ducati Pantah, Ducati F1, Ducati 750 Paso (1987-1990), Ducati 750 Sport (1988-1990), Ducati 860 GT/GTS, Ducati 900 GTS, Ducati Hailwood Rep, Ducati 900 Darmah (1977-1978), Ducati 906 Paso (1988-1989), Ducati 1000 R1 Hailwood Ref., Hesketh, Horex HRD 600, Horex 500/600 Columbus, Laverda 750 SF2, Laverda 750 SFC, Laverda 750 SF3, Laverda 1000 3C (1974-1978), Laverda 1000 3CL (1976-1981), Laverda 1000 RGS/RGA, Laverda 1000 SFC, Laverda 1200 (1978-1979), Laverda 1200 TS/Mirage (1981), MZ ETZ 125/150/250/300 (1985-1992), Norton Classic (1989), Norton Interpol (1989), Triumph T140 (1985-1988 Brembo)

Throttle cable

Ball end at twistgrip

10117500-z 10117500 GU10117500 10 11 75 00
 1011 7500 1011.7500 10.11.75.00

Dimensions:
Inner length 946mm, outer length 869mm

Single 100cm length of pipe used for oil return and breather applications depending on model. Can be used as gearbox breather on Tonti 5 speed gearboxes

Use hose clip FUA00004

823956080

Dimensions:
1000mm x 16mm x 9mm

Zadi ignition switch with 2 keys

4 male spade type connectors on underside, replaces original switch with bullet connectors. See ELA10005 for female spade connectors, FRA14735 for switch cover and FRA19741 for rubber wiring boot

 31735360 GU31735360 31 73 53 60
 3173 5360 3173.5360 31.73.53.60

Also fits Benelli 750 Sei (series 2) - fits with minor modification

Dimensions:
54mm long overall (including pins) x 29mm

Complete (rev counter) tacho cable

We advise you to measure your existing cable before ordering in case you have a non standard set up.

19768100-z 19768100 GU19768100 19 76 81 00
 1976 8100 1976.8100 19.76.81.00

Dimensions:
588mm

Complete Speedo (odometer) cable

We advise you to measure your existing cable before ordering in case you have a non standard set up.

27760410-z 27760410 GU27760410 27 76 04 10
 2776 0410 2776.0410 27.76.04.10

Dimensions:
968mm inner length

NGK CPR8EB-9 spark plug

See TOA05931 for spark plug spanner

 887481 MG887481

Air filter, cylindrical paper cartridge type

See SIA10422 for a reusable K & N air filter

AP8104211

Dimensions:
128mm external diameter, x 112mm

Air filter, flat paper cartridge type

See SIA10425 for a reusable performance air filter

AP8104242

Dimensions:
115mm x 155mm x 28mm

Oil pressure sender, M12 thread, male bullet connector

This oil pressure sensor supercedes Guzzi no. 12768700. Some small twins also require adapter 19055800 (or ELA19720 can be fitted in place of this switch). Check which type your small twin uses before replacing.

See ENA12640 for replacement crush washer if required

 17768750 GU17768750 17 76 87 50
 1776 8750 1776.8750 17.76.87.50

Dimensions:
M12 thread, 46mm x 21mm bolt flats
