Front crank oil seal

Directional oil seal. Also known as Guzzi ref. 886363

 90402842 GU90402842 90 40 28 42
 9040 2842 9040.2842 90.40.28.42

Dimensions:
28mm x 38mm x 7mm

Closing throttle cable

Also see opening cable CAA01880 . Replaces Guzzi ref. 01117530, 01117500. Only one cable is required. We advise you to measure your existing cable before ordering in case you have a non standard set up

 01117880 GU01117880 01 11 78 80
 0111 7880 0111.7880 01.11.78.80

Dimensions:
Free Length 125mm, Outer: 1030 mm

NGK Iridium DR9EIX high performance spark plug

Due to the properties of Iridium, the spark plugs centre electrode can be made with a much smaller diameter than with platinum, Gold or gold palladium and copper/nickel types without sacrificing service life. See TOA00014 for spark plug spanner

Circlip for gudgeon pin

Gudgeon pin clip also known as Guzzi ref. 90351039

 90351038 GU90351038 90 35 10 38
 9035 1038 9035.1038 90.35.10.38

Dimensions:
24.5mm diameter x 1.5mm

1mm pinion shim for rear drive box. Also replaces wheel bearing shim 12615801 on loop frame models

 19355300 GU19355300 19 35 53 00
 1935 5300 1935.5300 19.35.53.00

Dimensions:
28mm OD x 1mm

Front crankshaft oil seal

Viton seal

90412237-Z

Dimensions:
22mm x 35mm x 7mm

Gearbox output shaft oil seal

 90401424 GU90401424 90 40 14 24
 9040 1424 9040.1424 90.40.14.24

Rotational oil seal for crownwheel carrier in drive box on post 1974 big twins. Front crank oil seal on loop frame models

Also known as Guzzi ref. 90403850 and used on 850 GT and loop frame models for front crank oil seal ( 90403851 )

 90413850 GU90413850 90 41 38 50
 9041 3850 9041.3850 90.41.38.50

Dimensions:
38mm x 50 mm x 7mm

Bearing seal used for front wheel on loop frame models with 2 shoe front drum and rear wheel

2 required for front wheel, 2 required for rear wheel

 90403249 GU90403249 90 40 32 49
 9040 3249 9040.3249 90.40.32.49

Dimensions:
48mm OD

Upper fork bush

Split fork bush, also known as Guzzi ref. 30526761

 599505 MG599505

Dimensions:
40mm ID
