12 volt ignition coil for models equipped with points, Bosch or Motoplat ignition systems, includes HT lead. Terminal layout is different to original coils- see photos.

Not for Digiplex models. Also known as Guzzi ref. 19716500, 19716520

 31716560 GU31716560 31 71 65 60
 3171 6560 3171.6560 31.71.65.60

Dimensions:
80mm mounting spacing

Marelli condenser with cable and mount bracket

2 required

 14715433 GU14715433 14 71 54 33
 1471 5433 1471.5433 14.71.54.33

Dimensions:
body measures 30mm x 18mm, lead measures 140mm

Condenser with mount bracket

2 required

 19708620 GU19708620 19 70 86 20
 1970 8620 1970.8620 19.70.86.20

Dimensions:
body measures 22mm x 21mm diameter

Gearbox return spring

Selector spring also known as Guzzi ref. 32238210, 14238200, 14238201, 28238260. This 3 coil spring is a Guzzi update to the 4 coil spring used on some small twins

 28238261 GU28238261 28 23 82 61
 2823 8261 2823.8261 28.23.82.61

Dimensions:
64mm x 42mm overall

Input shaft oil seal for gearbox

 90403245 GU90403245 90 40 32 45
 9040 3245 9040.3245 90.40.32.45

Dimensions:
45mm OD

Throttle cable for models with standard high top PHF pumper carbs

We advise you to measure your existing cable before ordering in case you have a non standard set up. Use these cables if fitting a Tommaselli 2C twin pull throttle with high top PHF 36 carbs

14117550-z 14117550 GU14117550 14 11 75 50
 1411 7550 1411.7550 14.11.75.50

Dimensions:
895mm outer, 1040mm inner length including angled section, 80mm free length

Manual left hand petrol tap with nut and fuel level sender. On and off settings.

Will also fit most other Moto Guzzi tanks from 1976 to 1991, these can be used to replace discontinued electric taps but please measure first and check you have space for outlet pipe

23105370-z 23105370 GU23105370 23 10 53 70
 2310 5370 2310.5370 23.10.53.70

Dimensions:
M16 x 1 threaded section, 140mm sender

PS 15 rear master cylinder with plastic reservoir

Brembo no. 10.2426.00. Replaces original part with cast reservoir which is no longer available. Also replaces guzzi ref. 29667000. Please note that reservoir is slightly taller than the original, and you may need swap the operating arm from your old master cylinder if this is a different type. This part can be used instead BRC19001 but you will also need to fit a brake reservoir

 10438802 GU10438802 10 43 88 02
 1043 8802 1043.8802 10.43.88.02

Brand new left hand original "Lego" type switchgear with switches for indicators, flash, horn, high / low beam and park. Previously unavailable new and ideal for your restoration project.

Comes with unattached 12 pin molex connector, rubber boot and pins ready for you to wire into your existing loom.

Dimensions:
670mm lead

Bearing carrier and disc carrier for spoked rear wheel on wide fork 850 and 1000cc models, used for front spoked wheel on narrow fork 750 models

1 required per wheel

14620301-z 14620301 GU14620301 14 62 03 01
 1462 0301 1462.0301 14.62.03.01

Dimensions:
22mm wide at disc mounting
